How to add a dark theme to your Qt application

Dark themes are now available for Windows 10 and Mac and it is increasingly expected that desktop applications will offer a dark theme. Previously Qt support for dark themes was patchy. But I am happy to say that it now seems to work fine with Qt 5.12.2, and I have added dark themes to both Windows and Mac versions of my Easy Data Transform and Hyper Plan applications.

Easy Data Transform for Mac with a dark theme:

Easy Data Transform for Windows with a dark theme:

Hyper Plan for Mac with a dark theme:

Hyper Plan for Windows with a dark theme:

I haven’t decided yet whether to add a dark theme to PerfectTablePlan.

Adding dark themes was a fair amount of work. But a lot of that was scouring forums to work out how to integrate with macOS and Windows. Hopefully this article will mean you don’t have to duplicate that work.

Dark themes work a bit differently on Windows and Mac. On Windows changing the UI theme to dark won’t directly affect your Qt application. But you can use an application stylesheet to set the appearance. On Mac changing the UI theme to dark will automatically change your application palette, unless you explicitly block this in your Info.plist file (see below). On both platforms you will need to change any icons you have set to the appropriate light/dark version when the theme changes. Some of this may change in future as dark themes are more closely integrated into Qt on Windows and Mac.

macOS

You can add the following helper functions to a .mm (Objective-C) file:

#include "Mac.h"
#import <Cocoa/Cocoa.h>

bool macDarkThemeAvailable()
{
    if (__builtin_available(macOS 10.14, *))
    {
        return true;
    }
    else
    {
        return false;
    }
}

bool macIsInDarkTheme()
{
    if (__builtin_available(macOS 10.14, *))
    {
        auto appearance = [NSApp.effectiveAppearance bestMatchFromAppearancesWithNames:
                @[ NSAppearanceNameAqua, NSAppearanceNameDarkAqua ]];
        return [appearance isEqualToString:NSAppearanceNameDarkAqua];
    }
    return false;
}

void macSetToDarkTheme()
{
   // https://stackoverflow.com/questions/55925862/how-can-i-set-my-os-x-application-theme-in-code
   if (__builtin_available(macOS 10.14, *))
   {
        [NSApp setAppearance:[NSAppearance appearanceNamed:NSAppearanceNameDarkAqua]];
   }
}

void macSetToLightTheme()
{
    // https://stackoverflow.com/questions/55925862/how-can-i-set-my-os-x-application-theme-in-code
    if (__builtin_available(macOS 10.14, *))
    {
        [NSApp setAppearance:[NSAppearance appearanceNamed:NSAppearanceNameAqua]];
    }
}

void macSetToAutoTheme()
{
    if (__builtin_available(macOS 10.14, *))
    {
        [NSApp setAppearance:nil];
    }
}

The macSetToLightTheme() and macSetToDarkTheme() are useful if you want to give the user the option to ignore the OS theme. Call macSetToAutoTheme() to set it back to the default.

Corresponding header file:

#ifndef MAC_H
#define MAC_H

bool macDarkThemeAvailable();
bool macIsInDarkTheme();
void macSetToDarkTheme();
void macSetToLightTheme();
void macSetToAutoTheme();

#endif // MAC_H

You then need to add these files into your .pro file:

macx {
   ...
   HEADERS += Mac.h
   OBJECTIVE_SOURCES += Mac.mm
}

You can detect a change of theme by overriding changeEvent():

void MainWindow::changeEvent( QEvent* e )
{
#ifdef Q_OS_MACX
    if ( e->type() == QEvent::PaletteChange )
    {
        // update icons to appropriate theme
        ...
    }
#endif
    QMainWindow::changeEvent( e );
}

If you decide you *don’t* want to add a dark theme to your Mac app, the you should add the bold entry below to your Info.plist file:

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
<plist version="1.0">
<dict>
    ...
    <key>NSRequiresAquaSystemAppearance</key>
    <true/>
</dict>
</plist>

This will then force it to be shown in a light theme, regardless of the theme the operating system is in.

Windows

To set a dark theme palette you can use a stylesheet:

QFile f( ":qdarkstyle/style.qss" );
if ( !f.exists() )
{
   qWarning() << "Unable to set dark stylesheet, file not found";
}
else
{
   f.open( QFile::ReadOnly | QFile::Text );
   QTextStream ts( &f );
   getApp()->setStyleSheet( ts.readAll() );
}

The stylesheet I used was a modified version of qdarkstyle from a few years ago.

To unset the stylesheet and return to a light theme just call:

getApp()->setStyleSheet( "" );

Alternatively you can do it by changing the application palette.

Windows helper functions:

bool windowsDarkThemeAvailable()
{
    // dark mode supported Windows 10 1809 10.0.17763 onward
    // https://stackoverflow.com/questions/53501268/win10-dark-theme-how-to-use-in-winapi
    if ( QOperatingSystemVersion::current().majorVersion() == 10 )
    {
        return QOperatingSystemVersion::current().microVersion() >= 17763;
    }
    else if ( QOperatingSystemVersion::current().majorVersion() > 10 )
    {
        return true;
    }
    else
    {
        return false;
    }
}

bool windowsIsInDarkTheme()
{
    QSettings settings( "HKEY_CURRENT_USER\\Software\\Microsoft\\Windows\\CurrentVersion\\Themes\\Personalize", QSettings::NativeFormat );
    return settings.value( "AppsUseLightTheme", 1 ).toInt() == 0;
}

Currently there seems to be no way to conect to a signal or event that shows the theme has changed in Windows. So I connected to a signal from a QTimer that fires every 5 seconds to check windowsIsInDarkTheme().

Icons

When the theme changes you potentially need to update any icons you have set, e.g. for the toolbar.

In a light theme you can usually set the active icons and let Qt calculate the corresponding disabled icons. This doesn’t work for a dark theme as you want the disabled icons to be darker than the enabled icons, rather than lighter. So you can either calculate the disabled icons programmatically or you can provide a set of disabled icons as well. I opted for the former.

Assuming your icons are set up as resources under :/icons/dark and :/icons/light you can do something like this:

QString getResourceName( const QString& iconName, bool dark )
{
    return QString( ":/icons/%1/%2" ).arg( dark ? "dark" : "light" ).arg( iconName );
}

QPixmap getPixmapResource( const QString& iconName, bool dark )
{
    QString resourceName = getResourceName( iconName, dark );
    QPixmap pixmap = QPixmap( resourceName );
    Q_ASSERT( !pixmap.isNull() );
    return pixmap;
}

QIcon getIconResource( const QString& iconName, bool dark )
{
    QIcon icon;
    QPixmap pixmap = getPixmapResource( iconName, dark );
    icon.addPixmap( pixmap );
    if ( dark )
    {
        // automatic disabled icon is no good for dark
        // paint transparent black to get disabled look
        QPainter p( &pixmap );
        p.fillRect( pixmap.rect(), QColor( 48, 47, 47, 128 ) );
        icon.addPixmap( pixmap, QIcon::Disabled );
    }
    return icon;
}

Then you can reset the icon for the appropriate theme with:

bool isDark()
{
#ifdef Q_OS_MACX
   return macIsInDarkTheme();
#else
   return windowsIsInDarkTheme();
#endif
}
...
myButton->setIcon( getIconResource( "my_icon.png", isDark() ) );
...

You may also be able to update icons through QIcon::setThemeName(). But I didn’t explore this in any detail.

Note that you probably don’t want the enabled icons to be pure white, as it is a bit too visually jarring against a dark theme.

How to notarize your software on macOS

** Please note: WordPress keeps mangling my code examples by changing double dash to single dash. I tried to fix it. But it changed them all back again! If anyone knows how to get around this, please put something in the comments. **

Apple now wants you to ‘notarize’ your software. This is a process where you upload your software to Apple’s server so it can be scanned and certified malware free. This will probably become compulsory at some point, even (especially?) if your software isn’t in the Apple app store. Apple says:

Give users even more confidence in your software by submitting it to Apple to be notarized. The service automatically scans your Developer ID-signed software and performs security checks. When it’s ready to export for distribution, a ticket is attached to your software to let Gatekeeper know it’s been notarized.

When users on macOS Mojave first open a notarized app, installer package, or disk image, they’ll see a more streamlined Gatekeeper dialog and have confidence that it is not known malware.

Note that in an upcoming release of macOS, Gatekeeper will require Developer ID signed software to be notarized by Apple.

Documentation on notarization is a bit thin on the ground, especially if you want to notarize software that wasn’t built using XCode (I build my software using QtCreator). So I am writing up my experiences here.

First you need to ensure you have macOS 10.14 and XCode 10 installed (with command line tools) and you need a current Apple developer account.

Codesign your app with ‘hardened runtime’ using –options runtime :

codesign –deep –force –verify –verbose –sign “Developer ID Application:<developer id>” –options runtime <app file>

E.g.:

codesign –deep –force –verify –verbose –sign “Developer ID Application: Acme Ltd” –options runtime myApp.app

A ‘hardened runtime’ limits the data and resourced an application can access. I’m not sure what the exact ramification of this are. But it doesn’t seem to have restrict my software from doing anything it could do previously.

You can check the signing with:

codesign –verify –verbose=4 <app file>

E.g.:

codesign –verify –verbose=4 myApp.app

Now package your app into a .dmg (e.g. using DropDMG). Then upload the .dmg to Apple’s servers:

xcrun altool -t osx -f <dmg file> –primary-bundle-id <bundle id> –notarize-app –username <username>

E.g.:

xcrun altool -t osx -f myApp.dmg –primary-bundle-id com.acme.myapp –notarize-app –username me@acme.com

You will be prompted for your Apple developer password (or you can include it on the command line).

You now have to wait a few minutes. If the upload is successful “No errors uploading ” will be shown and a unique ID will be returned. You then have to use this to request your upload be scanned:

xcrun altool –notarization-info <notarize ID> -u <username>

E.g.:

xcrun altool –notarization-info xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxx -u me@acme.com

You will be prompted for your Apple developer password (or you can include it on the command line).

Hopefully you will see “Status Message: Package Approved”. If the notarization fails, you should be sent a link to an online log file describing the issue. If the notarization completes successfully you need to ‘staple’ the results to your .dmg:

xcrun stapler staple -v <dmg file>

E.g.:

xcrun stapler staple -v myApp.dmg

The stapler outputs a log including some odd phrases. Mine included: “Humanity must endure”, “Let’s see how that works out. “, “Adding 1 blobs to superblob. What about Blob?” and “Enjoy”. Weird. Hopefully it will end with “The staple and validate action worked!”.

Finally you can unpack your .dmg into a .app and verify it with:

spctl -a -v <app file>

E.g.

spctl -a -v /Applications/myApp.app

On macOS 10.14 (but not earlier OSs) it should say “source=Notarized Developer ID”. Your software should now run on 10.14 without a warning dialog. Congratulations!

It all seems rather clumsy. As you have to wait asynchronously for the unique ID to be returned from step 1 before you can complete step 2, it is not easy to fully automate in a script. This is a major pain the arse. If anyone works out a way to automate it the whole process, please let me know.

Here are some links to the various posts that I gleaned this information from:

https://cycling74.com/forums/apple-notarizing-for-mojave-10-14-and-beyond
https://www.mbsplugins.de/archive/2018-11-02/Notarize_apps_for_MacOS
https://forum.xojo.com/50655-how-to-codesign-and-notarise-your-app-for-macos-10-14-and-highe
https://forum.xojo.com/49408-10-14-hardened-runtime-and-app-notarization/11
https://stackoverflow.com/questions/53112078/how-to-upload-dmg-file-for-notarization-in-xcode
https://lapcatsoftware.com/articles/debugging-mojave.html
