This is a guest post from fellow software developer, Simon Kravis.
Few developers would choose their development platform on the merits of their respective Integrated Development Environments (IDEs) but it happens that applications developed in Windows need to be made available on the Mac platform.
There are many environments offering cross-platform (Mac, Windows and sometimes Android) functionality, but close inspection shows that they all have limitations. Visual Studio (the native Windows IDE) can produce apps which will run on a Mac using .Net Core – but only if they are command line apps on Windows. Other environments (like Xamarin) do support interfaces, but only involving simple controls like text boxes or drop-downs. There are other cross-platform IDEs (such as Qt) which offer better graphics support, but they are not cheap and the extent of their support is not evident. If you need functionality such as computer vision, there seems to be no alternative to creating a separate code base for the Mac. Once you start on this path it becomes obvious that Macs handle graphics (and interfaces) very differently from Windows.
Macs have evolved rather more than PCs over the decades: they abandoned their proprietary Mac operating system in favour of UNIX in 1999, adopting the NeXTSTEP platform created by NeXT. Apple originally used PowerPC chips, replacing them with Intel Core processors in 2006, and they are currently transitioning to RISC chips. The Mac NeXTSTEP programming language was Objective C, developed in the 1980s and this is still supported, although the modern Swift language was introduced in 2014, and the Xcode IDE appeared in 2003. Xcode is free, even for teams. It uses the Cocoa API, which is accessible from other environments. The current release (MacOS 13.0) supports both Objective-C and Swift and is also used for developing iPhone and iPad apps. Mac operating systems since Catalina (released in 2019) are 64-bit only. Xcode can only develop apps for Apple operating systems, notably iOS, which powers the iPhone. Most of the web questions and examples relate to iOS rather than MacOS. MacOS uses different frameworks from iOS, so some functions used in iOS are not available in MacOS, or have different parameters.
The Windows IDE (Visual Studio) dates from 1997, when it bundled together Visual Basic, Visual Fox Pro and Visual Source Safe and Visual C++. It has an open architecture based on plug-ins and supports 36 different programming languages, but the major ones are C#, VB.Net and C++. Visual Studio can develop apps for any platform via the .NetCore framework, but capability for non-Windows platforms is limited. The Community edition is free, and has almost all the functionality of paid versions.
Both Visual Studio and Xcode are highly complex applications. They both have graphical interface builders where controls are dragged from a library onto a form. Each application has a vocal supporters and detractors. My experience comes from about 5 years with Visual Studio developing C# applications. Before this I worked with Visual Basic for Applications in Microsoft Access, so I am well-versed in the Microsoft way of doing things.
Like most complex applications, Visual Studio and Xcode each have plenty of bugs, often producing completely unhelpful error messages. Reporting an Xcode bug through standard channels resulted in … nothing. Not even an automated message saying “Thank you for feedback. It will be used to improve future versions”. I haven’t even tried to report a Visual Studio bug, but I suspect that the much larger user base for Visual Studio will mean that workarounds are more readily available, even if the giant ship of Microsoft takes years to respond.
Moving to the Mac and Xcode for development was a shock as I found I didn’t know how to do the most basic things. String manipulation (used in most applications) in Objective C is highly verbose compared to C#. Google was invaluable for finding answers – mostly they were from Stack Overflow, but often from 10 or more years ago, sometimes from Apple Developer Forums. As Xcode has changed considerably since then, answers often had to be adjusted before they could be used. Another problem is that functionality once provided externally has since been incorporated into Cocoa, so attempts to find a current version of a component (or framework as they called in Cocoa) are often unsuccessful.
MacOS provides more native functionality than Windows. Features such as computer vision and PDF generation are included in MacOS, rather than requiring the use of 3rd party components, which may not as robust as desired, and may require a license for commercial use. However, documentation of MacOS functionality, if present at all, was rarely useful. A few times I asked questions on Stack Overflow which attracted the ire of the Mac gurus for either through having obvious (to them) answers or through not conforming to the forum guidelines (in their opinion). However, the integration of NuGet with Visual Studio provides easy access to the massive number of 3rd party libraries available for .Net on Windows.
The model-view-controller paradigm used on the Mac took some getting used to, as did the design of the main Xcode screen. Sometimes a useful display would disappear and I had difficulty in finding it how to bring it back. I often had to resort to retrieving earlier versions from the excellent Time Machine backup. Form design is similar on both platforms – dragging and dropping components from a library. Both Xcode and Visual Studio have bugs, as would be expected for such complex apps. Events from components are generated automatically in Windows, but have to be defined on the Mac (as Actions). References to the component you’ve added also need to be defined on the Mac (as Outlets) and are not a property of the component, whereas on Windows they are.
The Xcode environment provides only basic facilities from scratch: if you need to do something more sophisticated you’ll have to Google around to find out how. Once you know – it’s easy, but the learning curve for Xcode is much higher than for Visual Studio.
Rather than starting from scratch with the Mac version of my Caption Pro app, which uses local computer vision functionality to detect multiple photos, changes image dimensions and adds text to images, I found an existing open-source project on GitHub with similar basic functionality. This dated from 7 years ago and used Objective-C, so that was the language I opted for. An immediate handicap was that many of the answers I found to my questions used Swift in their example code, which is not interconvertible with Objective-C in the way that C# and VB.Net are. iOS applications for the iPhone (which are most common) use different frameworks from Mac apps, and routines in them sometimes have completely different syntax.
The user interfaces for the Mac and Windows versions look quite different, as shown below. There are some basic differences – menus appear separately to the application window on the Mac and are locked to the top of the screen, whereas Windows menus are part of the application screen. Toolbars offer access to common functionality on the Mac. Differences also arise from the fact the Mac application was adapted from existing code rather than created from scratch.
Open-source examples (often from GitHub) are useful, but rarely work out-of-the- box. Sometimes the modifications need are minor – like defining the development team- but sometimes it’s not possible to get them to build in a current version of Xcode.
Debugging on Xcode is frustrating – the call stack frequently contains assembler (which is perhaps why app performance tends to be better on Macs), and the debug variables window does not list all relevant variable values. Variable types may not be correct – Boolean values may appear as dates, and sometimes variables cannot even be evaluated by po (print out) statements. Printing out structure variables may show nothing. Despite the generally superior performance of Mac apps, building apps in Xcode appears to be much slower than in Visual Studio on similar vintage machines, and after code stops at a breakpoint, it may take a long time before the variables window is filled. Deployment of Mac apps can still be done on an ad-hoc basis, but you have to register as an Apple Developer to avoid blockages in installation arising from being an ‘untrusted source’. Bypassing these blockages is more than a matter of clicking “Install anyway” so it’s hard to avoid forking out US$100 per year for registration. Windows has similar blockages, which can be bypassed with a code-signing certificate. These certificates are available from many vendors, and are slightly cheaper than Apple developer registration, but the process of obtaining one may be very involved.
Ad-hoc deployment is somewhat easier on the Mac than on Windows, but the method of doing it via Archive generation is anything but obvious. Mac applications are actually disk images and applications keep all of relevant files in a folder. This makes uninstallation a matter of dragging the application icon into the recycle bin, a far simpler process than on Windows. dmg files are not recognized by IIS web servers (and may not be by Apache either), so unless the file type is registered, download from a web site will not be possible.
Apple pioneered the App Store for iPhones (it is the only way in which iPhone apps can be installed) and Mac apps can also be put there. Apple takes a commission of 30% (or 15% if you are a small company) and they review all apps before adding them. Passing the review process may be a lngthy process, as not all problems are detected in a review cycle. Fixing these issues and resubmitting may result in further problems coming to light. The review process may also be somewhat arbitrary. One App Store app presented an interface in German by default. English was available as Preferences option, but only after guessing where the Preferences option was located. App Store apps operate within a sandbox, which places restrictions on filesystem operations. Whether App Store deployment makes economic sense depends on the nature of the app, its market and price structure. Its advantages are that it targets the 16% of desktop users who use Macs, and streamlines installation (and payment, if applicable). The App Store supports ‘freemium’ pricing, where additional features are made available to paying users, but apps with free trial periods are shown as being free but with ‘in-app purchases’, which annoys some users.
Windows deployment can use .msi files, which have been around for decades, but are not easily installed by non-admin users. Self-extracting executables are more tractable, but 3rd party tools have to be used to create them. Windows 10 introduced Universal Windows Programs, which are easier to install and can be placed in the Microsoft Store, which operates in a similar way to the Apple App store, but for Windows desktops and tablets.
A key question which is very difficult to answer is “How long will it take me to convert my Windows app to run on a Mac?” Factors affecting this are app complexity, functionality and programmer skill. The time between starting work on the Mac app and first deploying it on the company web site was about 3 months, but the amount of time spent on the project each day varied between zero and 3 or 4 hours. If you are a paid resource, then the cost of a cross-platform IDE may be justified, but the requirement for local computer vision functionality added a great deal of complexity to my requirements, which is one reason why I opted for a separate code base. Substantial evaluation would be required before deciding if a cross-platform environment could support any required functionality.
Simon Kravis runs Aleka Consulting, a small software and consultancy company in Canberra, Australia specializing in information management and offering a number of software products. He has mainly developed scientific and engineering programs, starting in the era of paper tape.
